Enabling Smarter Industrial, Agricultural & Solar Operations through Long-Range, Low-Power IoT Monitoring with LoRa® Technology

From noisy factories to sprawling farmlands and solar fields, reliable real-time monitoring was once a distant dream. Traditional wired and Wi-Fi systems failed to cover vast areas or withstand interference. By introducing a LoRa (Long Range) IoT-based solution, operations across various industries now gain uninterrupted, long-distance data visibility, enabling smarter, safer, and more sustainable decisions.

Client

Operators across industrial, agricultural, and solar sectors needed a scalable, low-power IoT system for reliable, long-range monitoring.

Industry

Industrial Automation | Agriculture | Renewable Energy Monitoring

Timeline

12 months

Scroll Down

Jump to Section

3 Min Read time

Read Time

Quick Snapshot

Each client required reliable real-time data collection across large, complex areas where wired and Wi-Fi systems were unreliable.

A wireless monitoring ecosystem was built using ESP32-C3 microcontrollers, EBYTE E22-900T22D-V2 LoRa modules (SX1262), and the ThingsBoard IoT cloud.

Sensor data for environment, air quality, and energy was transmitted via LoRa® to a central gateway, then to the cloud through MQTT, enabling live dashboards, reports, and automated alerts.

This unified system enhanced operational safety, reduced maintenance costs, lowered energy consumption, and enabled more effective environmental management.

Challenges

Each of these challenges presented an opportunity to design a wireless, low-maintenance, and configurable system capable of operating independently and reliably, regardless of the conditions.

Coverage Limitations

Industrial zones and solar fields extended across kilometers, far exceeding the effective range of Wi-Fi and BLE networks.

Signal Interference

Dense machinery, metal structures, and environmental factors disrupted wireless communication.

High Deployment Costs

Running wired infrastructure or installing repeaters across large areas was both costly and impractical.

Data Gaps

Without continuous data feeds, operators lacked environmental insight, creating inefficiencies and compliance risks.

Energy Constraints

Remote operations required autonomous systems capable of running for months on battery or solar power.

Scalability and Maintenance

Expanding legacy systems to include new nodes often required reconfiguration and additional wiring.

Solution

A unified, scalable LoRa-based IoT architecture was developed and deployed across multiple scenarios—industrial, agricultural, and renewable energy sites—each engineered for long-range communication, low-power operation, and centralized visibility.

Industrial Indoor
Climate Monitoring

The system used temperature, humidity, CO₂, VOC, PM2.5, light, and noise level sensors to maintain compliance in production floors, warehouses, and data centers. Real-time readings were transmitted via LoRa to the gateway, which handled MQTT communication to the ThingsBoard Cloud. This provided continuous monitoring, safety alerts, and historical analysis for HVAC optimization.

Smart Farm
Weather Monitoring

Equipped with soil moisture, rain, light, and soil pH sensors, the nodes enabled farmers to optimize their irrigation systems and predict weather-dependent productivity. Long-distance communication allowed farms spanning several kilometers to be covered with only a few gateways, drastically reducing operational overhead.

Solar Farm
Performance Monitoring

Sensor arrays included pyranometers (for irradiance measurement), wind sensors, rainfall detectors, soil moisture sensors, and temperature thermocouples mounted on solar panels. These nodes ensured proactive maintenance, tracking efficiency dips due to temperature or cleanliness, while ThingsBoard dashboards visualized solar yield and performance across the farm.

Each system followed a modular design principle, meaning the same underlying technology stack could be reused and customized to fit site-specific needs—whether for environmental, climatic, or energy data.

Technology Used

Delivering reliable, intelligent, and scalable IoT monitoring from scratch required a combination of hardware engineering, embedded systems, wireless communication design, and cloud integration expertise.

1. ESP32-C3 Microcontroller

Acts as the computational core of each sensor node and gateway.
Integrates Wi-Fi and BLE for gateway communication and edge updates.
Consumes minimal power with support for deep-sleep modes, extending battery life in field deployments.

2. EBYTE E22-900T22D-V2 LoRa® Module (SX1262 Chip)

Operates on the 868/915 MHz spectrum, ideal for long-distance communication up to 7 km in open areas.
Provides exceptional link reliability due to high sensitivity and low packet loss, even in noisy environments.
Supports UART transparent mode, allowing fast and direct communication with the ESP32-C3, simplifying firmware design.

3. Sensor Suite

Environmental Monitoring: BME280 (Temperature, Humidity, Pressure)
Air Quality: CO₂ (NDIR), VOC/Gas (CCS811/MQ Series), PM2.5 (Dust)
Light and Sound: BH1750/LDR (Lux), Noise Sensor (dB monitoring)
Agriculture: Soil Moisture, Rain Detection, Soil pH, Optical Light Sensors
Renewable Energy: Pyranometer (Irradiance), Wind Speed (Anemometer), Thermocouple Sensors for solar panel surfaces

4. Software & Connectivity Architecture

Firmware Framework: ESP-IDF-based code optimized for low power and real-time operation.
LoRa® Integration Layer: Communicates via UART AT Commands for reliability and low-throughput power consumption.
MQTT Protocol: Secures the transmission of sensor payloads to cloud servers with minimal bandwidth.
ThingsBoard IoT Platform: Provides the cloud visualization, analytics, and alerting interface, including:
- Live dashboards and trend visualizations.
- Historical data storage and compliance reporting.
- Custom alerts through email/SMS for threshold events.

5. Power Management

Designed for battery and solar-powered operation.
Field-deployable enclosures with onboard charging controllers.
Power optimization at both firmware and hardware levels to ensure months of autonomous operation.

This robust combination of embedded hardware, wireless communication, and IoT software integration turned standalone sensors into a cohesive ecosystem that continuously learns, reports, and automates environmental monitoring tasks.

Results

Industrial Plants: Maintained compliance with air quality and workplace safety standards; HVAC systems automatically optimized based on live temperature/humidity feedback.
Farm Operations: Improved crop yield and reduced irrigation costs through precision, weather-based automation; early alerts prevented crop damage.
Solar Installations: Boosted energy output by monitoring panel cleanliness and temperature; reduced service downtime through proactive maintenance alerts.

Each deployment scaled efficiently, enabling multi-node and multi-site connectivity under a single IoT dashboard—ensuring performance monitoring, safety, and cost savings became continuous and measurable outcomes.

Conclusion

By engineering an ecosystem of ESP32-C3 microcontrollers, EBYTE E22-900T22D-V2 LoRa modules, precision sensors, and cloud-connected dashboards, this LoRa®-enabled monitoring system delivers unmatched reliability, long-range performance, and energy efficiency.

Industries now benefit from adaptive intelligence, which features real-time insights, proactive maintenance, and measurable optimization, all managed through a single centralized interface. This innovation—powered through seamless integration and advanced IoT development—proves that connectivity, automation, and sustainability are not separate goals, but parts of the same intelligent system.

Through a blend of embedded engineering, wireless communication design, and IoT cloud integration, Technostacks continues to enable connected ecosystems that redefine operational visibility and transparency.
